07. 인공지능 및 파이썬 9-18장


* 이전 독서시 활용한 기본 제공 데이터를 그대로 구현한 코드

1. 필기체 인식 예

# 데이터 전처리

from tensorflow.keras.datasets import mnist
from tensorflow.keras.utils import to_categorical

import matplotlib.pyplot as plt
import sys

# X_train, y_train : 학습에 사용될 학습셋 데이터
# X_test, y_test : 테스트에 사용될 테스트셋 데이터
(X_train, y_train), (X_test, y_test) = mnist.load_data()

print("학습셋 이미지 수: %d개" % (X_train.shape[0]))
print("테스트셋 이미지 수: %d개" % (X_test.shape[0]))

plt.imshow(X_train[0], cmap='Greys')
plt.show()

for x in X_train[0]:
    for i in x:
        sys.stdout.write("%-3s" % i)
    sys.stdout.write('\n')

X_train = X_train.reshape(X_train.shape[0], 784)
X_train = X_train.astype('float64')
X_train = X_train / 255

X_test = X_test.reshape(X_test.shape[0], 784).astype('float64') / 255

print("class : %d " % (y_train[0]))
y_train = to_categorical(y_train, 10)
y_test = to_categorical(y_test, 10)

print(y_train[0])

# 인식 코드 작성

from tensorflow.keras.models import Sequential
from tensorflow.keras.layers import Dense
from tensorflow.keras.callbacks import ModelCheckpoint, EarlyStopping
from tensorflow.keras.datasets import mnist
from tensorflow.keras.utils import to_categorical

import matplotlib.pyplot as plt
import numpy as np
import os

(X_train, y_train), (X_test, y_test) = mnist.load_data()

X_train = X_train.reshape(X_train.shape[0], 784).astype('float32') / 255
X_test = X_test.reshape(X_test.shape[0], 784).astype('float32') / 255

y_train = to_categorical(y_train, 10)
y_test = to_categorical(y_test, 10)

model = Sequential()
model.add(Dense(512, input_dim=784, activation='relu'))
model.add(Dense(10, activation='softmax'))
model.summary()
model.compile(loss='categorical_crossentropy', optimizer='adam', metrics=['accuracy'])

modelpath = "./MNIST_MLP.hdf5"
checkpointer = ModelCheckpoint(filepath=modelpath, monitor='val_loss', verbose=1, save_best_only=True)
early_stopping_callback = EarlyStopping(monitor='val_loss', patience=10)
history = model.fit(X_train, y_train, validation_split=0.25, epochs=30, batch_size=200, verbose=0, callbacks=[early_stopping_callback, checkpointer])
print("\n Test Accuracy: %.4f" % (model.evaluate(X_test, y_test)[1]))

# 검증셋과 학습셋의 오차
y_vloss = history.history['val_loss']
y_loss = history.history['loss']

# 시각화
x_len = np.arange(len(y_loss))
plt.plot(x_len, y_vloss, marker='.', c="red", label='Testset_loss')
plt.plot(x_len, y_loss, marker='.', c="blue", label='Trainset_loss')
plt.legend(loc='upper right')
plt.grid()
plt.xlabel('epoch')
plt.ylabel('loss')
plt.show()

1-2. 같은 문제를 콘볼루션 신경망으로 작성

from tensorflow.keras.models import Sequential
from tensorflow.keras.layers import Dense, Dropout, Flatten, Conv2D, MaxPooling2D
from tensorflow.keras.callbacks import ModelCheckpoint,EarlyStopping
from tensorflow.keras.datasets import mnist
from tensorflow.keras.utils import to_categorical

import matplotlib.pyplot as plt
import numpy as np

# 데이터 import
(X_train, y_train), (X_test, y_test) = mnist.load_data()
X_train = X_train.reshape(X_train.shape[0], 28, 28, 1).astype('float32') / 255
X_test = X_test.reshape(X_test.shape[0], 28, 28, 1).astype('float32') / 255
y_train = to_categorical(y_train)
y_test = to_categorical(y_test)
model = Sequential()
model.add(Conv2D(32, kernel_size=(3, 3), input_shape=(28, 28, 1), activation='relu'))
model.add(Conv2D(64, (3, 3), activation='relu'))
model.add(MaxPooling2D(pool_size=(2,2)))
model.add(Dropout(0.25))
model.add(Flatten())
model.add(Dense(128,  activation='relu'))
model.add(Dropout(0.5))
model.add(Dense(10, activation='softmax'))


model.compile(loss='categorical_crossentropy',
              optimizer='adam',
              metrics=['accuracy'])

modelpath="./MNIST_CNN.hdf5"
checkpointer = ModelCheckpoint(filepath=modelpath, monitor='val_loss', verbose=1, save_best_only=True)
early_stopping_callback = EarlyStopping(monitor='val_loss', patience=10)


history = model.fit(X_train, y_train, validation_split=0.25, epochs=30, batch_size=200, verbose=0, callbacks=[early_stopping_callback,checkpointer])
print("\n Test Accuracy: %.4f" % (model.evaluate(X_test, y_test)[1]))

# 검증셋과 학습셋 오차 저장
y_vloss = history.history['val_loss']
y_loss = history.history['loss']

# 시각화
x_len = np.arange(len(y_loss))
plt.plot(x_len, y_vloss, marker='.', c="red", label='Testset_loss')
plt.plot(x_len, y_loss, marker='.', c="blue", label='Trainset_loss')
plt.legend(loc='upper right')
plt.grid()
plt.xlabel('epoch')
plt.ylabel('loss')
plt.show()

2. 생성 인공지능 GAN - 이미지생성

from tensorflow.keras.datasets import mnist
from tensorflow.keras.layers import Input, Dense, Reshape,Flatten, Dropout
from tensorflow.keras.layers import BatchNormalization, Activation, LeakyReLU, UpSampling2D, Conv2D
from tensorflow.keras.models import Sequential, Model

import numpy as np
import matplotlib.pyplot as plt

# 생성자
generator = Sequential()
generator.add(Dense(128*7*7, input_dim=100, activation=LeakyReLU(0.2)))
generator.add(BatchNormalization())
generator.add(Reshape((7, 7, 128)))
generator.add(UpSampling2D())
generator.add(Conv2D(64, kernel_size=5, padding='same'))
generator.add(BatchNormalization())
generator.add(Activation(LeakyReLU(0.2)))
generator.add(UpSampling2D())
generator.add(Conv2D(1, kernel_size=5, padding='same', activation='tanh'))

# 판별자
discriminator = Sequential()
discriminator.add(Conv2D(64, kernel_size=5, strides=2, input_shape=(28,28,1), padding="same"))
discriminator.add(Activation(LeakyReLU(0.2)))
discriminator.add(Dropout(0.3))
discriminator.add(Conv2D(128, kernel_size=5, strides=2, padding="same"))
discriminator.add(Activation(LeakyReLU(0.2)))
discriminator.add(Dropout(0.3))
discriminator.add(Flatten())
discriminator.add(Dense(1, activation='sigmoid'))
discriminator.compile(loss='binary_crossentropy', optimizer='adam')
discriminator.trainable = False

# gan 생성
ginput = Input(shape=(100,))
dis_output = discriminator(generator(ginput))
gan = Model(ginput, dis_output)
gan.compile(loss='binary_crossentropy', optimizer='adam')
gan.summary()
def gan_train(epoch, batch_size, saving_interval):

# MNIST 데이터 로드
    (X_train, _), (_, _) = mnist.load_data()
    X_train = X_train.reshape(X_train.shape[0], 28, 28, 1).astype('float32')

    # 127.5를 뺀 후 127.5로 나누어서 -1~1 사이의 값으로 수정
    X_train = (X_train - 127.5) / 127.5

    true = np.ones((batch_size, 1))
    fake = np.zeros((batch_size, 1))

    for i in range(epoch):
        idx = np.random.randint(0, X_train.shape[0], batch_size)
        imgs = X_train[idx]
        d_loss_real = discriminator.train_on_batch(imgs, true)

        noise = np.random.normal(0, 1, (batch_size, 100))
        gen_imgs = generator.predict(noise)
        d_loss_fake = discriminator.train_on_batch(gen_imgs, fake)

        # 판별자 생성자 간 오차
        d_loss = 0.5 * np.add(d_loss_real, d_loss_fake)
        g_loss = gan.train_on_batch(noise, true)

        print('epoch:%d' % i, ' d_loss:%.4f' % d_loss, ' g_loss:%.4f' % g_loss)

        # 중간 과정을 이미지 저장
        if i % saving_interval == 0:
        # r, c = 5, 5
        noise = np.random.normal(0, 1, (25, 100))
        gen_imgs = generator.predict(noise)

        # Rescale images 0 - 1
        gen_imgs = 0.5 * gen_imgs + 0.5

        fig, axs = plt.subplots(5, 5)
        count = 0
        for j in range(5):
            for k in range(5):
                axs[j, k].imshow(gen_imgs[count, :, :, 0], cmap='gray')
                axs[j, k].axis('off')
                count += 1
        fig.savefig("gan_images/gan_mnist_%d.png" % i)

# 2000번 반복되고(+1을 하는 것에 주의) 각 배치 크기는 32, 200번일때 저장
gan_train(2001, 32, 200)
